On this tutorial, we carry out a complicated single-cell RNA-seq evaluation workflow utilizing Scanpy on the PBMC-3k benchmark dataset. We begin by loading the dataset, inspecting its construction, and making use of high quality management checks to judge gene counts, complete counts, mitochondrial content material, and ribosomal gene alerts. We then filter low-quality cells and genes, detect potential doublets with Scrublet, normalize the info, apply log transformation, and determine extremely variable genes for downstream evaluation. Additionally, we rating cell-cycle phases, regress out undesirable technical variation, scale the info, and scale back dimensionality utilizing PCA, UMAP, and t-SNE. We additionally cluster cells with the Leiden algorithm, determine marker genes, annotate cell populations utilizing canonical PBMC markers, discover trajectory construction with PAGA and diffusion pseudotime, calculate a customized interferon-response rating, and eventually save the totally analyzed AnnData object for future use.
!pip set up -q scanpy leidenalg python-igraph scrublet
import scanpy as sc
import numpy as np
import pandas as pd
import matplotlib.pyplot as plt
import warnings
warnings.filterwarnings("ignore")
sc.settings.verbosity = 3
sc.settings.set_figure_params(dpi=80, facecolor="white", figsize=(5, 5))
sc.logging.print_header()
adata = sc.datasets.pbmc3k()
adata.var_names_make_unique()
print(adata)
adata.var["mt"] = adata.var_names.str.startswith("MT-")
adata.var["ribo"] = adata.var_names.str.startswith(("RPS", "RPL"))
sc.pp.calculate_qc_metrics(
adata, qc_vars=["mt", "ribo"], percent_top=None, log1p=False, inplace=True
)
sc.pl.violin(
adata,
["n_genes_by_counts", "total_counts", "pct_counts_mt"],
jitter=0.4, multi_panel=True,
)
sc.pl.scatter(adata, x="total_counts", y="pct_counts_mt")
sc.pl.scatter(adata, x="total_counts", y="n_genes_by_counts")We set up the required single-cell evaluation libraries and import Scanpy, NumPy, Pandas, Matplotlib, and warning controls. We load the PBMC-3k benchmark dataset, make gene names distinctive, and examine the AnnData object construction. We then calculate high quality management metrics for mitochondrial and ribosomal genes and visualize count-level high quality patterns utilizing violin and scatter plots.
sc.pp.filter_cells(adata, min_genes=200)
sc.pp.filter_genes(adata, min_cells=3)
adata = adata[adata.obs.n_genes_by_counts < 2500, :].copy()
adata = adata[adata.obs.pct_counts_mt < 5, :].copy()
sc.pp.scrublet(adata)
print("Predicted doublets:", int(adata.obs["predicted_doublet"].sum()))
adata = adata[~adata.obs["predicted_doublet"], :].copy()
adata.layers["counts"] = adata.X.copy()
sc.pp.normalize_total(adata, target_sum=1e4)
sc.pp.log1p(adata)
sc.pp.highly_variable_genes(adata, min_mean=0.0125, max_mean=3, min_disp=0.5)
sc.pl.highly_variable_genes(adata)
adata.uncooked = adata
adata = adata[:, adata.var.highly_variable].copy()We filter out low-quality cells and barely detected genes to enhance the reliability of the dataset. We use Scrublet via Scanpy to determine predicted doublets and take away them earlier than deeper evaluation. We then protect uncooked counts, normalize expression values, apply log transformation, choose extremely variable genes, and hold solely probably the most informative options.
s_genes = ["MCM5","PCNA","TYMS","FEN1","MCM2","MCM4","RRM1","UNG","GINS2",
"MCM6","CDCA7","DTL","PRIM1","UHRF1","HELLS","RFC2","NASP",
"RAD51AP1","GMNN","WDR76","SLBP","CCNE2","UBR7","POLD3","MSH2",
"ATAD2","RAD51","RRM2","CDC45","CDC6","EXO1","TIPIN","DSCC1",
"BLM","CASP8AP2","USP1","CLSPN","POLA1","CHAF1B","E2F8"]
g2m_genes = ["HMGB2","CDK1","NUSAP1","UBE2C","BIRC5","TPX2","TOP2A","NDC80",
"CKS2","NUF2","CKS1B","MKI67","TMPO","CENPF","TACC3","SMC4",
"CCNB2","CKAP2L","CKAP2","AURKB","BUB1","KIF11","ANP32E",
"TUBB4B","GTSE1","KIF20B","HJURP","CDCA3","CDC20","TTK",
"CDC25C","KIF2C","RANGAP1","NCAPD2","DLGAP5","CDCA2","CDCA8",
"ECT2","KIF23","HMMR","AURKA","PSRC1","ANLN","LBR","CKAP5",
"CENPE","NEK2","G2E3","CBX5","CENPA"]
s_genes = [g for g in s_genes if g in adata.var_names]
g2m_genes = [g for g in g2m_genes if g in adata.var_names]
sc.tl.score_genes_cell_cycle(adata, s_genes=s_genes, g2m_genes=g2m_genes)
sc.pp.regress_out(adata, ["total_counts", "pct_counts_mt"])
sc.pp.scale(adata, max_value=10)
sc.tl.pca(adata, svd_solver="arpack")
sc.pl.pca_variance_ratio(adata, log=True, n_pcs=50)
sc.pp.neighbors(adata, n_neighbors=10, n_pcs=40)
sc.tl.umap(adata)
sc.tl.tsne(adata, n_pcs=40)We outline S-phase and G2/M-phase marker genes and retain solely these current within the dataset. We rating every cell for cell-cycle section, regress out undesirable variation from complete counts and mitochondrial share, and scale the info for downstream modeling. We then run PCA, examine defined variance, assemble the neighborhood graph, and generate UMAP and t-SNE embeddings.
sc.tl.leiden(adata, decision=0.5, taste="igraph", n_iterations=2, directed=False)
sc.pl.umap(adata, colour="leiden", legend_loc="on knowledge", title="Leiden clusters")
sc.pl.tsne(adata, colour="leiden", legend_loc="on knowledge", title="t-SNE clusters")
sc.tl.rank_genes_groups(adata, "leiden", methodology="wilcoxon")
sc.pl.rank_genes_groups(adata, n_genes=20, sharey=False)
outcome = adata.uns["rank_genes_groups"]
teams = outcome["names"].dtype.names
top_df = pd.DataFrame({g: outcome["names"][g][:10] for g in teams})
print("nTop 10 markers per cluster:n", top_df)
marker_genes = {
"B-cell": ["CD79A", "MS4A1"],
"CD8 T-cell": ["CD8A", "CD8B"],
"CD4 T-cell": ["IL7R", "CD4"],
"NK": ["GNLY", "NKG7"],
"CD14 Monocyte": ["CD14", "LYZ"],
"FCGR3A Monocyte": ["FCGR3A", "MS4A7"],
"Dendritic": ["FCER1A", "CST3"],
"Megakaryocyte": ["PPBP"],
}
sc.pl.dotplot(adata, marker_genes, groupby="leiden", standard_scale="var")
sc.pl.stacked_violin(adata, marker_genes, groupby="leiden", swap_axes=True)We apply Leiden clustering to group cells based mostly on the neighborhood graph and visualize the clusters on UMAP and t-SNE plots. We carry out differential expression evaluation utilizing the Wilcoxon take a look at to determine the highest marker genes for every cluster. We then use canonical PBMC marker genes to help cell-type annotation via dot plots and stacked violin plots.
sc.tl.paga(adata, teams="leiden")
sc.pl.paga(adata, colour="leiden", threshold=0.1)
sc.tl.umap(adata, init_pos="paga")
sc.pl.umap(adata, colour="leiden", legend_loc="on knowledge")
sc.tl.diffmap(adata)
sc.pp.neighbors(adata, n_neighbors=10, use_rep="X_diffmap")
adata.uns["iroot"] = np.flatnonzero(adata.obs["leiden"] == adata.obs["leiden"].cat.classes[0])[0]
sc.tl.dpt(adata)
sc.pl.umap(adata, colour=["leiden", "dpt_pseudotime"], legend_loc="on knowledge")
ifn_genes = ["ISG15", "IFI6", "IFIT1", "IFIT3", "MX1", "OAS1", "STAT1", "IRF7"]
ifn_genes = [g for g in ifn_genes if g in adata.raw.var_names]
sc.tl.score_genes(adata, gene_list=ifn_genes, score_name="IFN_score")
sc.pl.umap(adata, colour="IFN_score", cmap="viridis")
adata.write("pbmc3k_analyzed.h5ad")
print("n Evaluation full — saved to pbmc3k_analyzed.h5ad")
print(adata)We run PAGA to mannequin connectivity between Leiden clusters and reinitialize UMAP utilizing the PAGA graph to acquire a clearer trajectory construction. We compute diffusion maps and diffusion pseudotime to discover doable development patterns throughout cell states. We additionally calculate an interferon-response gene-set rating, visualize it on UMAP, and save the ultimate analyzed object as an .h5ad file.
In conclusion, we constructed an end-to-end Scanpy pipeline for single-cell RNA-seq evaluation, remodeling uncooked PBMC knowledge into interpretable organic insights. We cleaned and preprocessed the dataset, eliminated noisy cells and doublets, chosen informative genes, and generated significant embeddings to visualise mobile construction. We then used Leiden clustering and differential expression evaluation to find marker genes and join clusters to recognized immune cell varieties. By including PAGA, diffusion pseudotime, and customized gene-set scoring, we prolonged the workflow past fundamental clustering and confirmed how Scanpy helps deeper organic interpretation. Finally, we had a saved .h5ad object that accommodates the processed knowledge, annotations, scores, clusters, and visible evaluation outcomes, prepared for downstream exploration or reporting.
